Lateral Liner

Repair laterals better than before without digging



Request a quote



Similar to the Spot Repairs, Nieltech offers Lateral Lining to fix cracks, broken sections of pipe, holes, offset joints and roots intrusions found in a lateral services, but it requires access to a cleanout at properly line or inside of residence.


The initial and crucial step is to properly clean and prep the host pipe. Prepping may include removal of roots, protrusions, and calcite buildup. Once the area is cleaned and the Spot Repair liner is pulled into place through a cleanout and it is moved into position. The processing stage is the same and it begins by inflating the mandrel with air which presses the liner against the host pipe.  Steam is introduced to the mandrel to activate the customized resin saturated in the crosslinks of the liner causing it to form a hard, impermeable pipe.


Nieltech also offers a solution to line connections at the main with the Formadrain T-liner technology.  Pulled into place with the help of three access points, it requires no excavation at all. Everything is made through existing cleanouts and manholes.  Using the same resin and fibreglass that’s proven, still steam cured, we can line a connection that features a “full main wrap” or “partial wrap”, providing the water tight fit and structural integrity it needs.


Sizes may vary from a 6’’ (150 mm) main combined with a 4’’ (100 mm) lateral, up to a 24’’ (600 mm) main combined with an 8’’ (200 mm) lateral.


Applications range from the standard municipal connection to industrial connections in plants, as well as a shared connection between residential buildings.


Features & Benefits:

  • Features

    • Only decreases pipe diameter by 5%

    • Installs in hours

    • Hundreds of miles of pipe have already been lined

    • More cost effective that conventional reconstruction methods

    • Eliminates environmental impact of removing and disposing of existing materials

    • Unlike other lining methods, the installation of PVC Fold-and-Form liners is done with steam and compressed air and does not require any mixing of chemicals at the jobsite.

    • Reduces nuisance odours resulting in fewer complaints from residents and busnesses compared to other lining methods

  • Benefits

    • No toxic chemicals

    • No Volatile Organic Compounds (VOC Free)

    • No digging

    • No surface disturbance

    • Stronger than the original pipe

    • Reduces the need for lengthy road closures, less impact to traffic flow

    • Reduces the danger of working adjacent to live traffic for an extended period of time

    • Factory-made, quality-controlled and tested to stringent ASTM standards

    • Highly resistant to chemicals and offers excellent abrasion and scratch resistant properties
